description
The SDT800-F8 consists of two phototransistors and two light-emitting diodes. Optocoupling between the input IR LED and the output phototransistor allows a high level of isolation while maintaining a low level of DC signal control. The SDT800-F8 provides an optically isolated approach to control many interface applications such as communications, industrial control, and instrumentation circuits.
The SDT800-F8 is a standard small 8-pin SSOP package.
characteristic
•vceo = 80 v
• Small 8-pin SSOP package (0.050 "lead pitch")
• Low input power consumption
• High stability
• CTR range 20 - 320% (optional binding)
• High isolation voltage (3750VRMS)
• Long life/high reliability
• ROHS/PB-FREE/REACH compatible
application
• Registers, copiers, vending machines
• System equipment, measuring instruments
• Feedback control circuit
Telecommunication equipment, telephones
•household appliance
• Digital logic input
• Input from the microprocessor
• Switching power supply
Absolute maximum rated parameters
The values shown are absolute pressure ratings. The functional operation of the device does not exist under these or any conditions beyond those defined in the Electrical Characteristics section of this document. Exposure to the absolute maximum rating can cause permanent damage to equipment and can adversely affect reliability
Storage temperature...................-55 + 150 °C
Operating temperature........................... -55 + 110°C
Continuous input current............................ 30 ma
Reverse input control voltage.................................. 5 v
Input power dissipation......................... 50 mw
Output power dissipation........................... 125 mW
Total power consumption.................................... 300 mw
Solder Temperature - Wave......... (10 sec) 260 °C
Welding temperature, IR reflow (10 seconds)................ 260°C
