XTR105PA

所属类别：放大器和线性器件
产品名称：2线带RTD传感器和激励源的变送器
厂商：BB
生产批号：15+
封装：DIP-14
库存状态：有库存
库存量：2510
最低订购量：5
详细资料：

Product Introduction

XTR105PA2 transmitter with RTD sensor and excitation source is produced by BB Factory, in DIP-14 package, batch number 15+, Microchip Centennial IC warehouse is currently in stock

description

The XTR105 is a monolithic 4-20mA, 2-wire current transmitter with two precision current sources. It provides complete current excitation for platinum RTD temperature sensors and bridges, instrumentation amplifiers, and current output circuitry on a single integrated circuit.

Versatile linearization circuitry provides a 2nd-order correction to the RTD, typically achieving a 40:1 improvement in linearity.

Instrumentation amplifier gain can be configured for a wide range of temperature or pressure measurements. Total unadjusted error of the complete current transmitter is low enough to permit use without adjustment in many applications. This includes zero output current drift, span drift, and nonlinearity. The XTR105 operates on loop power-supply voltages down to 7.5V.

The XTR105 is available in DIP-14 and SO-14 surface-mount packages and is specified for the –40°C to +85°C industrial temperature range.

characteristic

LOW UNADJUSTED ERROR
TWO PRECISION CURRENT SOURCES: 800 µA each
LINEARIZATION
2-OR 3-WIRE RTD OPERATION
LOW OFFSET DRIFT: 0.4 µV/°C
LOW OUTPUT CURRENT NOISE: 30NAPP
HIGH PSR: 110dB minimum
HIGH CMR: 86dB minimum
WIDE SUPPLY RANGE: 7.5V to 36V
DIP-14 AND SO-14 PACKAGES
APPLICATIONS
- INDUSTRIAL PROCESS CONTROL
- FACTORY AUTOMATION
- SCADA REMOTE DATA ACQUISITION
- REMOTE TEMPERATURE AND PRESSURE TRANSDUCERS
